Next.js is my go-to framework for building any type of frontend applications. It has many things pre-configured right out of the box. For example, you have built-in support for css, css modules, sass etc. It also comes with built-in support for environment variables and many other things. But one thing you cannot do directly in Next.js is to import SVG files in your components. In this article, I will explain the steps with which you can setup your nextjs project so that it can support importing svg files into your components.
I have created a basic Hello World NextJs app. See the file structure below.
We are going to use a babel plugin called babel-plugin-inline-react-svg.
npm install --save-dev babel-plugin-inline-react-svg
Now, lets add that plugin to our .babelrc
file.
Create a file named .babelrc
at the root of your project if it is not already present and add the following contents to it.
{
"presets": ["next/babel"],
"plugins": ["inline-react-svg"]
}
That is all we need to enable svgs in out Next.js project.
Let's test and see if it works. Let's import Next.js logo into our index page
// src/pages/index.js
import NextLogo from '../assets/nextjs.svg'
export default function Home() {
return (
<div>
<NextLogo width={100} height={100} fill={'red'} />
<h1>Hello Next.js</h1>
</div>
)
}
Now, run the development server with next dev
.
You can see here that NextJs logo is imported and rendered successfully.
There are many other ways to import svgs into your Next.js project. But I feel like this is the easiest way to do so.
Note:
If all you want is to import svg files in to your component as an image, and you don't want to add any svg specific properties like
fill
to it, then you can simply move the file to/public
folder of your Next.Js project and then use animg
tag to render svg.
<!-- nextjs.svg image is at public/nextjs.svg --> <!-- NextJs automatically serves files like images that are under 'public' folder --> <img src='/nextjs.svg' />
All the code that is written in this article is available on my github at pbteja1998/nextjs-with-svg
If you have any feedback or suggestions to improve the blog post, please leave them in the comments. I will try to improve the post accordingly.
If this blog post was helpful to you, please consider liking it and sharing it so that it reaches more people.
If you want to get notified as soon as I write a new blog post, you can click on Subscribe button at the top of this page. You can also follow me here at Bhanu Teja P or on twitter at @pbteja1998 to get updated.
Links and References
